Semantics and Ontology

Sometimes when we’re designing ontologies we’re faced with design choices that would lead us to create what we call “binary instances” or a situation where it will take the instantiation of two instances (often of different classes) in order to capture one concept.  For instance we may be considering creating a patient instance that is different from the corresponding person instance.

In an effort to move this design decision from the realm of arbitrary designers choice to something more principled, this article we explore the factors that go into a decision that leads to binary instances.

Some Examples

This section will outline some examples that we have come across, as it is often easier to work from a large pallet of examples than from abstractions.  Some of these examples may seem odd, some you may be surprised that anyone would consider them either one way or the other (binary or unary) but we have seen these at various times.

My guess is your background and predisposition will cause you to look at each one of these and say, either “obviously one instance” or “obviously two instances” but we suggest that any of these could go either way (a few are a bit of a stretch, but bear with it, we’re trying to make a point).  After the examples we introduce some principles that we think will lead to reasonably consistent decisions in this arena.

Statue v. Bronze

This is a classic philosophical argument.  What is the difference between the statue and the clay, or bronze.  The knee jerk reaction is to think they are two things, but consider: if you have a 10-pound statute made out of 10 pounds of bronze, when you go to ship it will you be charged for 20 pounds of freight or 10?

Person v. Employee

When you take on a job, are you two things (person and employee) or one thing (person who is an employee).  Hint: your employer and the Unemployment Insurance Agency are likely to come up with different answers for this one.

The Restrictions of Law v. The Text of Statute

If a lawmaker writes a law that says “it is illegal to turn right on a red light” and we model this.  What do we end up with?  Semantically the law is a restriction on behavior.  Tthere is a behavior (turning on the red) that the law intends to reduce the incidence of, either through cooperation or through punishment.  The question is: is the text of law (the literal words) its own object, separate from the meaning of the words.  If we are writing a text management system, or even a statute management system, there probably is only the text object (the system doesn’t care much about what the words mean).  However if we attempt to manage meaning, we need to consider that there are objects that represent the behavior we are interested in reducing, such that we could detect (via cameras say) behavior in the world that was in violation.  The question then becomes: is there one object that represents the restriction and a second that holds the text of the law, or is there just the restriction with a data type property that is the text?

A Creative Work v A Document

We know that there is a particular rendition of Moby Dick (in English or the Portuguese translation).  Certainly the English and Portuguese documents are different instances.  The real question is: is the recognition of the “work” (Moby Dick in the slightly abstract) a different instance, and do we need it dragging around with each rendition ( i.e. The Portuguese Moby Dick is a derivative of the creative work)

Government Organization v. Region Governed

When we speak of the Ukraine, are we referring to the governing body, which is an organization, or the region (recently diminished) that the government holds sway over.  Should we have one instance that represents the government and the region or two that are linked?

Specification v Model

When companies design and build products they often create specifications (is has 8 GB of memory, is 8 inches wide, and 2 inches tall, etc) and they also create “models” which they usually name (iPhone 6 for instance).  Is the specification a separate object from the model, or is there just one object?

Position v. Incumbent

Barack Obama is the President of the United States.  Is that two instances or one?

Actor v. Role

When Val Kilmer played Doc Holliday in Tombstone, was there one instance (Val Kilmer) who was a Person and was a role, or are there two instances, the role and the person?

Event v. Time Interval

We say an event is something that happened over a particular time interval.  So a particular concert, your attendance at the staff meeting Tuesday morning or World War II would all be considered events.  Each of course has a beginning and ending date and time.  The question is: is the time interval (May 22 from 9:00 AM to 10:00 AM) a separate instance from the staff meeting that occurred over that interval?

Diagnosis v. Disease

Up until the moment we are diagnosed with Cancer, or Diabetes, or even Toe nail fungus, we were unaware of our having the disease.  The diagnosis and the disease seem to coexist in most cases.  Are they two things or one?

Person v. Legal Person

We’ve seen systems that focus on the distinction between the flesh and blood person and the social artifact that is allowed to enter into contract. Two instances or one?

Organization v. Organization in Role

In some systems we’ve seen recently there is a distinction between an Organization (say Goldman Sachs) and an Organization in a Role (Goldman Sachs as an Underwriter v. Goldman Sachs as a Trader)

Contract Document v. Financial Agreement

Two parties agree to a complex financial transaction.  They paper it up with a contract that they sign.  If we model the essence of their agreement is it a separate instance from the written contract?  If not, how?

Person v. Patient

As a matter of history, your medical record is attached to your patient ID. If you’ve been to many medical institutions you have many patient IDs.  The question is, at any one of them are there two instances (Person and Patient) or one instance who is both Person and Patient?

Person v. Address

This one is hilarious.  Of course a person is separate from his or her address.  Except in almost every system ever built, where a persons address are merely attributes attached to the Person record.  When should we make the two distinct instances?

Planned Task v. Completed Task

If we plan a vacation, that is what we would call a Planned Event. We can book flights, hotels and the like and continue to add to this instance.  When we finally go on the vacation, we’ve created an actual or historical event.  Is there one event that changed state from planned to actual, or two events?

Person v. Sole Proprietor

Many independent contractors file tax returns as “Sole Proprietors” should we consider the person as a separate entity from the Sole Proprietor?

Part v. Catalog Item

Our definition of a Catalog Item, is the description of parts to a sufficient level of detail that a buyer would accept any item offered that met the description.  The Catalog Item typically has a part number, in retail a UPC.  The physical part also has the same UPC. Is the part a different item from the Catalog Item.

Customer v. (Person or Organization)

Is your customer, the person or organization that purchased your product or received your services, your customer, or is there another instance that represents your relationship with that entity?  Norms in your industry or limitations of your development environment probably color your answer here more than you think.

Relational technology makes it a relatively unnatural act to have say a Person table and an Organization table and then an order table with a foreign key to one or the other.  It’s far more “natural” in relational to have another table that represents the role of the customer.  Even if you have a “party” table, (which both the Person and the Organization extend) you have created another instance.  There is an id for each entry in the Party table, an id for each entry in the organization table (with a foreign key to the party) and an id for each entry in the person table (with a foreign key to the party).  Even without the role concept, there is an extra instance there.

Having a technology that allows us to have a single id to represent either a Person or Organization (Object Oriented or Semantic Technology) doesn’t get us completely out of the woods.  Now we could have the order refer directly to the Person or Organization.  Now the question becomes: should we?

I have been told by a data modeler from an Australian airline, that many of the people riding in an airplane are not customers.  The only ones they consider to be customers are those that belong to their frequent flyer program.  This makes some sense: they need to keep track of the miles and segments flown and accumulate them, only for the frequent flyers.  Additionally they incur obligations (to redeem balances for flights) but again only for the frequent flyers.

Pictorially

What we’re talking about is: are there two different things, that each have their own identity and properties, but that occur as a pair:

Or is there really just one thing, and it is the conventions of our speech that make us think there are two things when really all the properties are on the one thing.

Historical Perspective

Very often design decisions are influenced by the tools that we use to implement solutions. We protest that our designs are independent of target architectures but years of designing databases and then converting them to relational DBMSs lead to thinking in design terms that more easily translate.

One implication is that relational DBMSs (and most Object Oriented languages) tend to see a class as a template for instances.  This has a tendency to suggest that instances that have properties not shared by most of the other instances should be shuttled off to another table.  This almost always ends up creating additional primary keys in other tables and therefore binary instances for anything that is in both tables.  Designed brought up on relational will be inclined to think of the Person and the Patient as two different instances (this isn’t wrong as much as it is an indication of how our experience shapes our design choices)

In an analogous fashion, Object Oriented developers often invoke the Decorator Pattern (from the Gang of Four Pattern Language).  In the decorator pattern, some functionality has been shuffled off to a companion object that performs some of the functionality.  People from this background will tend to see the decorator as a separate individual.

Principles

Our starting point is ten principles: the first principle is: if at all possible have one instance.  The next eight principles suggest circumstances where one instance is not appropriate.  The last one, we call the ambiguity trump, says even if the principles suggest two instances are needed to model the concept in question, you have a final override to say: in this domain we don’t care enough about the distinction and are willing to live with the ambiguity.

Principle 1 – Ockham’s Razor – “Entities should not be multiplied needlessly” The first principle here says the benefit of the doubt goes to simplicity.  If you can represent the concept adequately with one instance, then by all means do so.  This should be the starting point.  Start by imagining one instance.

A second consideration for sticking with one, even if you are tempted by previous designs, habits, industry norms etc., is: with a binary set of objects, each property (predicate) that is to be attached to the concept, must be attached to one or the other.  If you find it difficult to decide which of the two the property belongs on, and you end up making arbitrary choices, you should really consider sticking with one.

Principle 2 – Cardinality – There are two aspects of the concept, and you’re considering whether to devote an instance to each.  One of the trump concepts is: can you have more than one of one aspect for each one of the other.  This is trickier than it first sounds, because we have fooled ourselves a lot over time with the way we couch the question.  One of the more clear cases is Person and Sole Proprietor.  Normally “Joe Jones, the plumber” is “Joe Jones” and when he files his taxes as a Sole Proprietor, the proprietorship is Joe.  Certainly he doesn’t have the firewall that he would have had, had he incorporated.  “Joe Jones, LLC” is recognized as a separate entity, can contract on its own behalf, and can, at least in theory, and declare bankruptcy without bankrupting Joe.  So the corporate case clearly two or more instances.  But at first it would seem that the sole proprietor should fall back to principle 1. However, it turns out that Joe can have multiple Sole Proprietorships.  It doesn’t happen often, but the existence of this case, makes the case that there must be something different between Joe and his Sole Proprietorship.

Principle 3 —   Potential instance Separation   — Is it possible to separate the two aspects that are being potentially represented by two instances?  Can you have the statute without the bronze or vice versa? (probably not and this argues for one) Can you have a waterway without the river (seems like a dry riverbed would satisfy the waterway without being a river, argues for potential separation) can some properties only logically apply to one of the pair and not the other?

Principle 4 – Separate properties – are there properties that would apply only to one of the instances?  For instance a property like “annual rainfall” would apply to a country region but not to the country government.   Often the different properties are shining a light on something deeper: that there are really two different types of things yearning to be separated.  In the case of the customer v Person or Organization, when you start entertaining adding properties (number of segments flown, miles about to expire etc.) you may realize that the entity with the balances is actually an agreement.

Principle 5 – Behavioral Impact – do most (all?) real world behaviors that apply to one also apply to the other? If we end an employee (employment really) have we ended (killed) the person (no wonder so many people cringe at the thought of termination).

Principle 6 – Inference from Definition – if we have formal definitions for the classes that make sense and an inference engine infers one to be a subclass of the other, that makes a case for one instance.  If the formal definitions put the two in disjoint classes, that is a strong argument for two instances.

Principle 7 – Identify Function – is the way we establish whether we already have an instance different in one or the other of these?  The identity function is a set of properties that we use to figure out whether we already have a particular instance in our database.  For instance if the identity function for Person is SSN + Date of Birth, and so is the identity function for employee, then it argues for one instance (it may be that the identity functions are wrong, but it should at least have us pause to reflect)

Principle 8 Granularity – Sometimes the two instances are trying to represent different levels of specificity.  For instance the difference between a Product Model and a Catalog Item may be level of detail.  If there are so many Product Models (or so little variation offered) then the Product Model and Catalog Item are at the same granularity and could be considered one instance.  If however they are at different levels of detail it makes the case for two instances.

Principle 9 – Temporal Difference – if one instance can end independent of the other, that is if they have different lifetimes, it suggests two instances.

Principle 10 – Tolerating Ambiguity  — there are cases where the above analysis suggest that there should be, semantically there are, two instances, but in our domain we really don’t care.  For instance we may be convinced that the GeoRegion of a country is different from the organization that governs it, but for our application or domain, which will not exercise any of the properties that would highlight that difference, we may say we really don’t care.  In this case we would suggest created a supertype of the two classes, and instantiating the supertype. So for instance you may create the class of GeoPoliticalEntities as the union of GeoRegion and Government Organization.  Make your instances of the supertype.  What this does is two fold:

• If you later decide that you do need to make a distinction, very few things you’ve built to date will be adversely affected. Anything that didn’t care whether you were talking about a region or a government will still not care after you make that distinction.
• If you have to interface with applications or domains that do make the distinction you will have what you need to incorporate their distinctions without upsetting your part of the system.

Re-examining the examples in light of the principles

Let’s return to the examples we introduced in the beginning and see if the principles shine any light on them.  Note: there will still be situations and domains that come to different conclusions, but we think these will be the conclusion informed from the above principles

Design Example	Proposal (one instance or two)	Principled Evidence
Statue v. Bronze	1	Principle 1, if you steal the statue you’ve stolen the bronze.  They’re really inseparable.  Also principle 7, how we establish the identity of the item (say we have an RFID tag on the statute it is also identifying the bronze)
Person v. Employee	2 for employers, 1 for unemployment	Principle 2 (you can have two jobs at a time) and principle 4 (your employee(ment) has a salary and seniority, you don’t, you have a birthday, your employee role doesn’t) and principle 9 (your job can end before you do) argue for 2 . However the Unemployment Division point of view argues for one.  A formal definition of someone who is employed (has at least one job) argues by principle 6 and the cardinality argument works the other way (your second job doesn’t alter the unemployment rate)
The Restrictions of Law v. The Text of Statute	2, and will have drug / drug interactions regardless of which patients you give the drugs.ed for one. ense tually an agreement.	Principle 8, granularity, and principle 2 cardinality.  When we start to interpret the law and get it to the point that we can begin having systems make at least some initial determination of the legality of an action, we find that a given law is many restrictions and at many levels of detail.
A Creative Work v A Document	2	Principle 2 (many derivatives from a single work)
Government Organization v. Region Governed	2	Principle 3 (we can separate the government from the land, and the land area can change without changing the government (sorry Ukraine) and principle 4 there are properties (rainfall) that apply to one and not the other
Specification v Model	2	Principle 8 in most cases the specification is at a lower level of detail than the product model (color is typically not part of the product model, but is typically in the specification, and most product domains different colors of the same product are not equally interchangeable)
Position v. Incumbent	2	Principle 9 (the position usually outlives the incumbent) and also occasionally principle 2 (can have co-presidents, two people in one position)
Actor v. Role	2	Principle 2 (Greater Tuna where two actors played all the roles)
Event v. Time Interval	1	Principle 6 (if a time interval is defined as having a start and an end, and so is an event, the event is a time interval)
Diagnosis v. Disease	2	Even though they initially co-exist, they soon develop their own time lines (principle 9) and properties
Person v. Legal Person	1	Principle 1 the person is the legal person, there isn’t another entity to hide behind.  None of the other principles argues for 2.  Legal Person is a type of Person, except in the case where it means Organization and in that case they are separate because of principle 6, they are disjoint and can’t be the same.
Organization v. Organization in Role	1, unless there is something formal set up to establish the extra role	Even though there is a bit of temptation from principle 9 it isn’t convincing.  If you participate as a buyer in one transaction and a seller in another are you three entities (yourself, you the buyer and you the seller) no not really.  Only if there is something formal set up.  In the airline industry the difference between a customer (has a role and therefore 2 entities) and a passenger (doesn’t one entity) is the frequent flyer agreement, where they are accumulating miles, getting various metal colors etc.
Contract Document v. Financial Agreement	1	Principle 1: the document is a representation of the agreement.  Where there are cardinality issues (the contract/ agreement contains many obligations) the cardinality is true of both, in the same way (if the contract has 6 obligations so does the agreement).
Person v. Patient	1	Principle 1. Unlike the cat with nine lives, the person that has 9 patient identities will die if any of them die, and will have drug / drug interactions regardless of which patients you give the drugs.
Person v. Address	2	Principle 1 Addresses are not attributes of people.  Addresses are attributes of buildings that people live in and work in which are obviously separate entities.
Planned Task v. Completed Task	1 for personal 2 for hospital, project management	Principle 2 (cardinality) trumps for any organization that has to keep track of either multiple appointments for one visit, or multiple reschedulings for the same task.  Where that doesn’t apply (say your vacation plan or personal todo’s) you can just have one task that transitions from planned to actual by merely being done, in a way that is principle 10, suggesting their may be a difference in personal task management but we just don’t care .
Person v. Sole Proprietor	2	Principle 2 cardinality, since we can have multiple sole proprietorships, we need to allow for two.
Part v. Catalog Item	2	Principle 4: while they both appear to have some of the same characteristics (weight for instance) they aren’t really the same.  That is a structural similarity not a semantic similarity.  A catalog with parts that weight thousands of pounds can be picked up with a single hand.
Customer v (Person or Organization)	1 unless there is a separate agreement, then 2	Principle 4: it is the existence of a separate agreement (separate from the individual order) that is the second instance.  Really the second instance isn’t “customer” but “customer agreement.”  In the absence of a second agreement (Master agreement, frequent shopper agreement etc.) there is only need for one.

In this column, I am making the case for Data Centric architectures for enterprises.  There is a huge economic advantage to converting to the data-centric approach, but curiously few companies are making the transition. One reason may be the confusion of Data Centric with Data Driven, and the belief that you are already on the road to data centric nirvana, when in fact you are nowhere near it.

Data-Centric

Data-centric refers to an architecture where data is the primary and permanent asset, and applications come and go.  In the data-centric architecture, the data model precedes the implementation of any given application and will be around and valid long after it is gone.

Many people may think this is what happens now or what should happen.  But it very rarely happens this way.  Businesses want functionality, and they purchase or build application systems.  Each application system has its own data model, and its code is inextricably tied with this data model.  It is extremely difficult to change the data model of an implemented application system, as there may be millions of lines of code dependent on the existing model.

Of course, this application is only one of hundreds or thousands of such systems in an enterprise.  Each application on its own has hundreds to thousands of tables and tens of thousands of attributes. These applications are very partially and very unstably “interfaced” to one another through some middleware that periodically schleps data from one database to another.

The data centric approach turns all this on its head. There is a data model—a semantic data model (but more on that will be in a subsequent white paper)—and each bit of application functionality reads and writes through the shared model.  If there is application functionality that calculates suggested reorder quantities for widgets, it will make its suggestion, and add it to the shared database, using the common core terms.  Any other system can access the suggestions and know what they mean.  If the reordering functionality goes away tomorrow, the suggestions will still be there.

Click here to read more on TDAN.com

Model Driven Development

Model Driven seems to be enjoying a bit of an upsurge lately.  Gartner has recently been hyping (is it fair to accuse the inventors of the hype curve of hyping something? or is it redundant?) what they call “low code/ no code” environments.

Perhaps they are picking up on and reporting a trend, or perhaps they are creating one.

Model Driven Development has been around for a long time. To back fill what this is and where it came from, I’m going to recount my experience with Model Driven, as I think it provides a first person narrative for most of what was happening in the field at the time.

I first encountered what would later be called Model Driven in the early 80’s when CAD (Computer Aided Design—of buildings and manufactured parts) was making software developers jealous.  Why didn’t we have workbenches where we could generate systems from designs?  Early experiments coalesced into CASE (Computer Aided Software Engineering).  I was running a custom ERP development project in the early 80’s (on an ICL Mainframe!) and we ended up building our own CASE platform.  The interesting thing about that platform was that we built the designs on recently acquired 8-bit microcomputers, which we then pushed to a compatible framework on the mainframe.  We were able to iterate our designs on the PCs, work out the logistical issues, and get a working prototype UI to review with the users before we committed to the build.

The framework built a scaffold of code based on the prototype and indicated where the custom code needed to go.  This forever changed my perspective on how systems could and should be built.

What we built was also being built at the same time by commercial vendors (we did this project in Papua, New Guinea and were pretty out of the loop as to what was happening in mainstream circles).  When we came up for air, we discovered what we had built was being called “I-CASE” (Integrated Computer Aided Software Engineering), which referred to the integration of design with development (seemed like that was the idea all along).  I assume Gartner would call this approach “low code” as there still was application code to be written for the non-boiler-plate functionality.

Next stop on my journey through model driven was another ERP custom build.  By the late 80’s a few new trends had emerged.  One was CAD was being invaded by parametric modeling.  Parametric modeling recognizes that many designs of physical products did not need to be redesigned by a human every time a small change was made to the input factors.  A motor mount could be designed in such a way that a change to the weight, position, and torque would drive a new design optimized for those new factors. The design of the trusses for a basketball court could be automatically redesigned if the span, weight, or snow load changed and the design of big box retail outlets could be derived from, among other things: wind shear, maximum rainfall, and seismic potential.

The other trend was AI (remember AI?  Oh yeah, of course you remember AI, which you forgot about from the early 90’s until Watson and Google’s renaissance of AI).

Being privy to these two trends, we decided to build a parametric model of applications and have the code generation be driven by AI.  Our goal was to be able to design a use case on a post-it note. We didn’t quite achieve our goal.  Most of our designs were up to a page long.  But this was a big improvement over what was on offer at the time.  We managed to generate 97% of the code in this very sophisticated ERP system.  While it was not a very big company, I have yet to see more complex requirements in any system I have seen (lot based inventory, multi-modal outbound logistics, a full ISO 9000 compliant laboratory information management system, in-line QA, complex real time product disposition based on physical and chemical characteristics of each lot).

In the mid 90’s we were working on systems for ambulatory health care.  We were building semantic models for our domain.  Instead of parametric modeling we defined all application behavior in a scripting language called tcl. One day we drew on a white board where all the tcl scripts fit in the architecture (they defined the UI, the constraint logic, the schema, etc.) It occurred to us that with the right architecture, the tcl code, and therefore the behavior of the application, could be reduced to data.  The architecture would interpret the data, and create the equivalent of application behavior.

We received what I believe to be the original patents on fully model driven application development (patent number 6,324,682).  We eventually built an architecture that would interpret the data models and build user interfaces, constraints, transactions, and even schemas.  We built several healthcare applications in this architecture and were rolling out many more when our need for capital and the collapse of the .com bubble ended this company.

I offer this up as a personal history of the “low code / no code” movement.  It is not only real, as far as we are concerned, but its value is underrepresented in the hype.

Data-Centric Architecture

More recently we have become attracted to the opportunity that lies in helping companies become data-centric.  This data-centric focus has mostly come from our work with semantics and enterprise ontology development.

What we discovered is that when an enterprise embraces the elegant core model that drives their business, all their problems become tractable.  Integration becomes a matter or conforming to the core.  New system development becomes building to a much, much simpler core model.

Most of these benefits come without embracing model driven.  There is amazing economy in reducing the size of your enterprise data model by two orders of magnitude.

Click here to read more on TDAN.com

In the previous installment (The Data Centric Revolution: The Evolution of the Data Centric Revolution Part One), we looked at some of the early trends in application development that foreshadowed the data centric revolution, including punched cards, magnetic tape, indexed files, databases, ERP, Data Warehouses and Operational Data Stores.

In this installment, we pick up the narrative with some of the more recent developments that are paving the way for a data centric future.

Master Data Management

Somewhere along the line, someone noticed (perhaps they harkened back to the reel-to-reel days) that there were two kinds of data that are, by now, mixed together in the databased application: transactional data and master data.  The master data was data about entities, such as Customers, Vendors, Equipment, Fixed Assets, or Products.  This master data was often replicated widely. For instance, every order entry system has to have yet another Customer table because of integrity constraints, if nothing else.

If you could just get all the master data in one place, you’d have made some headway.  In practice, it rarely happened. Why? In the first place, it’s pretty hard.  Most of the MDM packages are still using older, brittle technology, which makes it difficult to keep up with the many and various end-points to be connected.  Secondly, it only partially solved the problem, as each system still had to maintain a copy of the data, if for nothing else, for their data integrity constraints.  Finally, it only gave a partial solution to the use cases that justified it. For example, the 360^o view of the customer was a classic justification, but people didn’t want a 360 ^o view of the master data; they wanted to see the transaction data.  Our observation is that most companies that had the intention to implement several MDMs  gave up after about 1 ½ years when they found out they weren’t getting the payout they expected.

Canonical Message Model

Service Oriented Architecture (SOA) was created to address the dis-economy in the system integration space.  Instead of point-to-point interfacing, you could send transactional updates onto a bus (the Enterprise Service Bus), and allow rules on the bus to distribute the updates to where they are needed.

The plumbing of SOA works great.  It’s mostly about managing messages and queues and making sure messages don’t get lost, even if part of the architecture goes down. But most companies stalled out on their SOA implementations because they had not fully addressed their data issues.  Most companies took the APIs that each of their applications “published” and then put them on the bus as messages.  This essentially required all the other end-points to understand each other.  This was point-to-point interfacing over a bus.  To be sure, it is an improvement, but not as much as was expected.

Enter the Canonical Message Model.  This is a little-known approach that generally works well, where we’ve seen it applied.  The basic concept is to create an elegant [1] model of the data that is to be shared.  The trick is in the elegance.  If you can build a simple model that captures the distinctions that need to be communicated, there are tools that will help you build shared messages that are derived from the simple model.  Having a truly shared message is what gets one out of the point-to-point trap. Each application “talks” through messages to the shared model (which is only instantiated “in motion,” so the ODS problem versioning is much easier to solve), which in turn “talks” to the receiving application.

Click here to continue reading on TDAN.com

Of all the dangers that befall those on the journey to data centrism, by far the greatest danger is Appliosclerosis. Appliosclerosis, or as lay people know it- hardening of the silos, can strike any one at any time, but some are more prone to it than others. By the time Appliosclerosis has metastasized it may be too late, isolated and entrenched data models may already be firmly established in various vital departments, and extreme rationalization therapy may be the only option, perhaps followed by an intense taxo regimen.

In this brief piece we will lay out the symptoms that are most associated with the condition, and steps you can take to avoid early onset.

• Warning Sign 1: Fear of New Wheels – one of the most consistent early behavioral predictors of Appliosclerosis is Wheelophobia. This usually begins with executives making statements such as “Let’s not reinvent the wheel here.” This is an innocuous sounding bromide, after all, who wants yet another wheel? But this cliché is a Trojan Horse, and each of the Greek soldiers that come out of its belly carries the gift of yet another incompatible data model. Before you know it, the intention to avoid new wheels leaves the afflicted with a panoply of arbitrarily different and disconnected data models.
• Warning Sign 2: The Not (Not Invented Here Syndrome) – Curiously one of the most potent antibodies against Wheelophobia is the “Not Invented Here Syndrome (NIHS)” Those afflicted with NIHS (and it is generally believed to be hereditary) have a predisposition to custom build information systems whenever given a chance. While this does have many negative side effects, the positive side effect is that it curtails Appliosclerosis through two mechanisms. The first is by starving the nascent Applio tumors from developing by denying resources. The second is that NIHS is a very slow growing condition. Most organizations die with NIHS, not from it. The slow growth prompts some organizations to suppress the NIHS antibody with the bio-reactive NIHS complement (!NIHS).

Click here to read more on TDAN.com

This is the first of a regular series of columns from Dave McComb. Dave’s column, The Data-Centric Revolution, will appear every quarter. Please join TDAN.com in welcoming Dave to these pages and stop by often to see what he has to say.

We are in the early stages of what we believe will be a very long and gradual transition of corporate and government information systems. As the transition gets underway, many multi-billion dollar industries will be radically disrupted. Unlike many other disruptions, the revenues currently flowing to information systems companies will not merely be allocated to newer more nimble players. Much of the revenue in this sector will simply evaporate as we collectively discover what a large portion of the current amount spent on IT is unnecessary.

The benefits will mostly accrue to the consumers of information systems, and those benefits will be proportional to the speed and completeness that they embrace the change.

The Data-Centric Revolution in a Nutshell

In the data-centric enterprise, data will be a permanent shared asset and applications will come and go. When your re-ordering system no longer satisfies your changing requirements, you will bring in a new one, and let the old one go. There will be no data conversion. All analytics that worked before will continue to work. User interfaces, names of fields, and code values will be similar enough that very little training will be required.

Click here to read more on TDAN.com

Click here to read Chapter 2 of Dave’s book, “The Data-Centric Revolution”
