Google ontologist, Denny Vrandečić started a vigorous thread on the question of what constitutes a decade. See for example, the article: “People Can’t Even Agree On When The Decade Ends”. This, is a re-emergence of the question from 20 years ago on whether the new millennium will/did start on January 1 of 2000 or 2001.This is often posed as a mathematical conundrum, and math certainly plays a role here, but I think its more about terminology than it is about math. It reminds me of the question of whether Pluto is a planet. It is also relevant to ontologists.

The decade question is whether the 2020s did start on January 1, 2020 or will start on January 1, 2021. Denny noted that: “The job of an ontologist is to define concepts”. This is true, but ontologists often have to perform careful analysis to identify what the concepts are that really matter. Denny continued: “There are two ways to count calendar decades…”. I would put it differently and say: “The term ‘calendar decade’ is used to refer to at least two different concepts.”

At last count, there were 72 comments arguing exactly why one way or the other is correct. The useful and interesting part of the that discussion centers on identifying the nuanced differences between those two different concepts. The much less interesting part is arguing over which of these concepts deserves to be blessed with the term ‘calendar decade’. The latter is a social question, not an ontological question.

This brings us to Pluto. The interesting thing from an ontology perspective is to identify the various characteristics of bodies revolving around the sun, and then to identify which sets of characteristics correspond to important concepts that are worthy of having names. Finally, names have to be assigned: e.g. asteroid, moon, planet. The problem is that the term, ‘planet’, was initially used fairly informally to refer to one set of characteristics and it was later determined that it should be assigned to a different set of more precisely defined characteristics that scientists deemed to be more useful than the first. And so the term ‘planet’ now refers to a slightly different concept than it did before. The social uproar happened because the new concept no longer included Pluto.

A more massive social as well as political uproar arose in the past couple of decades around the term, ‘marriage’. The underlying ontological issues are similar. What are the key characteristics that constitute a useful concept that deserves a name? It used to be generally understood that a marriage was between a man and a woman, just like it used to be generally understood what a planet was. But our understanding and recognition of what is, should or could be, changes over time and so do the sets of characteristics that we think are deserving of a name.

The term planet was given a more restricted meaning, which excluded Pluto. The opposite was being argued in the case of marriage. People wanted a gender-neutral concept for a committed relationship; it was less restrictive. The term ‘marriage’ began to be used to include same-gender relationships.

I am aware that there are important differences between the decades, planets and marriages – but in all three cases, there are arguments about what the term should mean. Ironically and misnomeristically (if that’s a word), we refer to the worrying about what to call things as “just semantics”. Use of this phrase implies a terms-first perspective, i.e. you have a term, and you want to decide what it should mean. As an ontologist, I find it much more useful to identify the concepts first, and think of good terms afterwards. I wrote a series of blogs about this a few years ago.

What is my position on the decade question? If I was King, I would use the term ‘decade’ to refer to the set of years that start with the same 3 digits. Why? Maybe for the same reason that watching my car odometer change from 199999 to 200000 is more fun than watching it change from 200000 to 200001. The other proposed meaning for ‘calendar decade’ is not very interesting to me. So I would not bother to give it any name. But your mileage may vary.

Paving Cow Paths

Numerous modern day streets in downtown Boston defy logic – until you realize that the city fathers literally paved over the transit system created and used by cows.*  This gave the immediate benefit of getting places faster, while losing out on longer-term gains that designing a purpose-built street plan could have yielded.  This type of thing is pervasive in today’s enterprise ranging from computerizing paper forms to the plethora of information silos requiring an enterprise ontology– the subject of today’s blog.

Figure 1: Paving the cowpaths in Boston**

Semantic Technology

Semantic Arts works with a wide variety of companies and, unlike just a few years ago, it is now common for our new clients to already have a number of efforts and groups exploring semantic technology in-house.  Gone is fear of the ‘O word’. In its place are a range of projects and activities such as creating ontologies, working with triple stores, and creating proofs of concept. Unfortunately, what we see very little of is coordination of these efforts throughout the enterprise.

It would be mistaken to regard this as a misuse of the technology, because point solutions will often result in significant benefits locally – just like paving cow paths gave immediate gains. It’s more a missed opportunity in the form of a great irony. The very technology designed to break down silos gets used to build yet more silos – Semantic Silos.

Figure 2: Avoid Semantic Silos

Building semantic silos is an easy trap to fall into, because it takes a while to fully comprehend the power of semantic technology (or any other disruptive technology).  Information silos arise for many reasons, both technological and organizational.  Key technological factors include the inability of relational databases to (1) reuse schema and (2) uniquely identify data elements globally across databases.  That’s where the URI and RDF triples come in. It is hard to overstate the power of the URI in semantic technology. URIs uniquely identify not only data elements but also the schema elements. The former eliminates the need for joins, and the coordination of URIs makes the snapping together of disparate databases, well, a snap.  The latter enables something entirely foreign to relational technology: the ability to easily share and reuse all or parts of existing schema.

Enterprise Ontology

The key to avoiding semantic silos is to use an enterprise ontology, which is a small and elegant representation of the core concepts and relationships in your enterprise that are stable over time.  It is at the same time both a conceptual model, and a computable artifact that plays the role of a physical data schema. The enterprise ontology is a foundation for building more specialized ontologies that are loaded into dozens, hundreds or thousands of graph databases, called triple stores that are populated with data.  Data elements are also shared across multiple databases.  This is depicted in figure 3.

These stores can be used by many applications, not just one or two, as is common in today’s siloed, application-centric enterprise.  Collectively, these ontologies and their data form an enterprise knowledge graph. Such graphs are hugely important for modern companies such as Google, Facebook and LinkedIn.

Figure 3: The triple stores depicted in the top row are not silos. Globally unique URIs snap together to form a single enterprise knowledge graph that is accessible using federated SPARQL queries.  Letters denote ontology URIs and numbers denote data URIs.

Having built enterprise ontologies now in a variety of industries, we are confident in stating the surprising result that there are only a few hundred such concepts that form this core for any given enterprise.  This is what makes it possible to build an enterprise ontology, where building enterprise-wide data models has failed for decades. There is no need to have millions of attributes in the core model.

Summary and Conclusion

1. It is entirely possible to use semantic technology to develop point solutions around your enterprise and unwittingly end up recreating the very silos that semantic technology aims to get rid of.
2. We see this happening in organizations that are using semantic technology.
3. You don’t want to do that, you will miss out on some of the main benefits of the technology. The data will not snap together if there is no coordination.
4. The answer is to use an enterprise ontology as a core data model that is shared among all the applications and data stores that collectively make up your enterprise knowledge graph.
5. The URI is the hero: they are globally unique identifiers that allow seamless sharing of data and schema, joins are history.

Keep in mind that technology as enabler is only part of the story. To get real traction in breaking up silos also requires meeting plenty of social and organizational challenges and putting governance policies into place.  But that’s another topic for another day.

Don’t fall in the trap of paving the cow paths to semantic silos. Use an enterprise ontology to create the beginning of an integrated enterprise.

Afterward

See also the delightful and well-known poem by S.W. Foss called, “The Calf Path”.***

* Change Management: Paving the Cowpaths
https://www.fastcompany.com/1769710/change-management-paving-cowpaths

** Picture credit:
http://bostonography.com/2011/cartographic-greetings-from-boston/bostontownoldrenown/

*** https://m.poets.org/poetsorg/poem/calf-path

This blog follows from a recent blog by Dan Carey called Screwdrivers and Properties. It points to a longer whitepaper on the topic of avoiding property proliferation.

One way we keep the number of primitives small is to avoid creating a subproperty if its meaning is essentially the same as the superproperty, but has a more restricted domain or range. We illustrate this with an example in the genealogy domain. Suppose we have the property myeo:hasSibling and we want to model brothers and sisters. One way would be to create two subproperties, myeo:hasBrother and myeo:hasSister, whose ranges are myeo:Male and myeo:Female respectively, and define the class myeo:Brother as a property restriction class that means “any individual that is the brother of some person”.  In Manchester syntax, this looks like: “myeo:brotherOf some myeo:Person” where myeo:brotherOf is the inverse of myeo:hasBrother. Similarly we can define myeo:Sister as “myeo:sisterOf some myeo:Person”. This introduces two new classes and two new properties.

However, we can easily capture the semantics of brother and sister without introducing any new properties. We define the class myeo:Brother as “myeo:Male and myeo:siblingOf some myeo:Person” and myeo:Sister is defined as “myeo:Female and myeo:siblingOf some myeo:Person”. This way we can define the brother and sister concepts entirely in terms of existing primitives with the same number of classes and without creating any new properties.

The only thing that differs about myeo:hasBrother and myeo:hasSister compared to myeo:hasSiblingis that the former two properties have more restricted ranges (myeo:Male & myeo:Female vs. myeo:Person). Otherwise the meaning is identical.  We have essentially moved the semantics of brother from the domains of two new properties into the class expression that define the classes myeo:Brother and myeo:Sister  (see figure below).

Keeping the number of primitives low is not only more elegant, but it has practical value.  The fewer things you have, the easier it is to find what you need. Not only does it help during ontology development, it also helps downstream when others evolve and apply the ontology.

Michael Uschold gave a talk at the International Workshop on Completing and Debugging the Semantic Web held in Crete on May 30, 2016.   Here is a preview of the white paper, “Finding and Avoiding Bugs in Enterprise Ontologies” by Michael Uschold:

Abstract: We report on ten years of experience building enterprise ontologies for commercial clients. We describe key properties that an enterprise ontology should have, and illustrate them with many real world examples. They are: correctness, understandability, usability, and completeness. We give tips and guidelines for how best to use inference and explanations to identify and track down problems. We describe a variety of techniques that catch bugs that an inference engine will not find, at least not on its own. We describe the importance of populating the ontology with data to drive out more bugs. We point out some common ontology design practices in the community that lead to bugs in ontologies and in downstream semantic web applications based on the ontologies. These include proliferation of namespaces, proliferation of properties and inappropriate use of domain and range. We recommend doing things differently to prevent bugs from arising.

Introduction
In a manner analogous to software debugging, ontologies need to be rid of their flaws. The types of flaws to be found in an ontology are slightly different than those found in software, and revolve around the ideas of correctness, understandability, usability and completeness. We report on our experience (spanning more than a decade) in building and debugging enterprise ontologies for large companies in a wide variety of industries including: finance, healthcare, legal research, consumer products, electrical devices, manufacturing and digital assets. For the growing number of companies starting to use ontologies, the norm is to build a single ontology for a point solution in one corner of the business. For large companies, this leads to any number of independently developed ontologies resulting in many of the same heterogeneity problems that ontologies are supposed to solve. It would help if they all used the same upper ontology, but most upper ontologies are unsuitable for enterprise use. They are hard to understand and use because they are large and complex, containing much more than is necessary, or the focus is too academic to be of use in a business setting. So the first step is to start with a small, upper, enterprise ontology such as gist [McComb 2006], which includes core concepts relevant to almost any enterprise. The resulting enterprise ontology itself will consist of a mixture of concepts that are important to any enterprise in a given industry, and those that are important to a particular enterprise. An enterprise ontology plays the role of an upper ontology for all the ontologies in a company (Fig. 1). Major divisions will import and extend it. Ontologies that are specific to particular applications will, in turn, import and extend those. The enterprise ontology evolves to be the semantic foundation for all major software systems and databases that are core to the enterprise.

Click here to download the white paper.

Click here to download the presentation.

Figure 1: Quantum Entanglement

For a fuller treatment of this topic, see the whitepaper:  Quantum Entanglement, Flipping Out and Inverse Properties.

An OWL object property is a way that two individuals can be related to each other. Direction is important. For example, consider the two relationships:

1. being a parent: Michael has Joan as a parent, but Joan has Michael as a child.
2. guaranteeing a loan: the US government guarantees a loan, but the loan is guaranteed by the US government.

The direction corresponds to which party you are taking the perspective of, the parent or child, the guarantor, or the thing being guaranteed.  From the perspective of the child we might assert the triple: Michael :hasParent Joan.  Note that if Michael has Joan as a parent, then it is necessarily true that Joan has Michael as a child – and vice versa.  So asserting any triple results in the implicit assertion of an inverse triple.  It’s a bit like quantumly entangled particles, you cannot make a change to one w/o immediately affecting the other.

The property from the perspective of the other individual is called the inverse property. OWL provides a way to do refer to it in a triple.  For example, Joan :inverse(hasParent) Jennifer uses the hasParent property from Joan’s perspective to directly assert she has another child.

Figure 2: Property with anonymous inverse

If we wish, we can give the inverse property a name. Two good candidates are: hasChild, and parentOf.

Figure 3: Property with named inverse

The question naturally arises: when should you create an explicit named inverse property? There is no universal agreement on this issue, and at Semantic Arts, we have gone back and forth. Initially, we created them as a general rule, but then we noticed some down sides, so now we are more careful.   Below are four downsides of using named inverses (roughly in order of growing importance).  The first two relate to ease of learning and understanding the ontology. The last two relate inference and triple stores.

1. Names: It can be difficult to think of a good name for the inverse, so you might as well just use the syntax that explicitly says it is the inverse. It will likely be easier to understand.
2. Cluttered property hierarchy: Too many inverses can significantly clutter up the property hierarchy, making it difficult to find the property you need, and more generally, to learn and understand what properties there are in the ontology, and what they mean.
3. Slower Inference: Too many named inverses can significantly slow down inference
4. More Space: If you run inference and materialize the triples, a named inverse will double the number of triples that use a given property

So our current practice is to not create inverses unless we see a compelling reason to do so, and it is clear that those benefits outweigh the downsides.

We have a simple and effective way in gist to represent a wide range of physical quantities such as ‘82 kg’, ‘3 meters’ and ‘20 minutes’.  Each quantity has a number and a unit, such as ‘meter’ or ‘second’.  In addition to these simple units, we have unit multiplication and division to represent more complex units, e.g. for speed and acceleration. A standard speed unit is meters per second [m/s] and a standard acceleration unit is meters per second per second [(m/s)/s] or simply  [m/s^2].

Physicists as well as business people like to avoid the inconvenience of working with very large or very small numbers like 1000 meters, or .00000001 meters (a trillionth of a meter).  If you counted to see if the number of zeros was correct, you understand the problem.  So we create units like kilometer and picometer and give them conversion factors.   This works for any kind of unit (time, electric current, mass).  Note that the standard units have a conversion of 1 (which in normal parlance, means there is no conversion necessary). See figure 1 for some examples.

Figure 1: Example Quantities

We also have found a need for counting units like dozen or gross. For example, a wine merchant stocks and sells cases of 12 bottles of wine, so counting in dozens is more convenient than counting single bottles of wine.  What is interesting is that we can use the exact same structure for representing ‘4 dozen’ or  ‘7 gross’ as we do for representing things like ‘82 kg’ and ‘20 minutes’.   Take ‘4 dozen’, the number is 4, and the unit is ‘dozen’ and the conversion is 12.

In gist there is also a way to represent percentages, which we have always treated as a ratio. After all, when speaking of a percentage, there is always an explicit or implicit ratio somewhere.  For example:

1. “Shipment A has only 65% as much oil as shipment B” corresponds to the ratio:
   (No. of barrels in shipment A) / (No of barrels in shipment B) = .65
2. “There are 20% more grams of chocolate in the new package size” corresponds to the ratio:
   (NewQuantity – OldQuantity) / (OldQuantity) = .20

The units for the first example are barrels/barrels which cancel out leaving a pure number. Similarly, the units for the second example are grams/grams which again cancel out. In fact, every ratio unit that corresponds to a percentage will cancel out and leave a pure number. This means that although it may be useful to do so, we don’t need to represent gist:Percentage using a ratio unit.

Another thing that we never realized before is that, being a pure number,  a percentage can be represented in the same way we represent dozen or gross. The only difference is the conversion (12 vs. .01).  We can use this same structure to represent:

• parts per million (ppm), used by toxicologists say to measure amounts of mercury in tuna
• basis points (used by the Fed for describing interest rates)
  Investopedia defines a basis point as “a unit that is equal to 1/100 of 1%”

See figure 2 for the representational structures.

Figure 2: One structure for number units and ordinary units

Notice how ‘ 4 cm’ is very similar to ‘4 percent’:

• to convert 4 cm to its standard unit, we multiply 4 by the conversion factor of .01 resulting in .04 meters
• to convert 4 percent to its standard unit, we multiply 4 by the conversion factor of .01 resulting in .04 ??.

This means we can use the same computational mechanism to perform units conversion for pure numbers like 4 dozen and 4% as we do for ordinary physical quantities like 4 cm or 82 kg.

One question remains. Whereas we can readily see that the conversion factor for kilometer is based on the standard unit of meter, and the conversion factor for hour is based on the standard unit of second, what are the conversion factors of 12, .01 and .00001 (for dozen, percent and basis point) based on? What does it mean to have a standard unit for these pure numbers with a conversion of 1?

Let’s look to see how gist represents dozen and kilometer to see if that gives us any insight.

1. gist:kilometer is an instance of gist:DistanceUnit &
   ‘3 meters’ is an instance of gist:Extent &
   the base unit is gist:meterAnalogously:
2. gist:dozen is an instance of gist:CountingUnit,
   ‘4 dozen’ is an instance of gist:Count &
   the base unit is gist:each

Curiously, while ‘meter’ actually means something to us, and we know what it means to say ‘3 meters’, it strange to think what ‘3 eaches’ could possibly mean.  I invite you to stare at the following table for a while and see some analogies.

Figure 3: Standard Unit for Pure Number Quanties

Then notice that:

1. 4 dozen = 48 eaches
2. 4 dozen = 48 (just a simple number)
3. Therefore, 48 must equal 48 eaches (because both are equal to 4 dozen).

But what is it, such that if you have 48 of them gives you the number 48?  The answer is the number one:  48 x 1 = 1.  So the meaning of gist:each is the number one acting as a unit. This is a mathematical abstraction. The ??’s in figure 2 stand for ‘each’ which is the standard number unit. So when you say ‘3 eaches’ it is just 3 of the number one which is just the pure number 3.  As an aside, we can also say that ‘each’ is the identity element for unit multiplication and division. This is analogous to the number 1 being the identity element for multiplication and division of numbers.

• You can multiply or divide any number by 1 and you get that number back.
• You can multiply or divide any unit by each (which means one) and get that unit back.

Note that while conceptually they mean the same thing, syntactically gist:each is very different from the number one as a number whose datatype is say integer, or float.

Notice that for these pure numbers in convenient sized units, we are usually counting things: how many dozens, how many basis or percentage points, or how many parts per million.  We refer to ‘each’ thing as ‘one’ thing being counted.  So that links gist:each to the number one.  Thus, despite the awkwardness of speaking of ‘3 eaches’ the names ‘Count’, ‘CountingUnit’ and ‘each’ are quite reasonable.

Finally, insofar as all instances of CountingUnits are based on the number one, and all instances of Count represent pure numbers, we can think of every CountingUnits as a degenerate unit, and we can think of gist:Count as a degenerate quantity.  A ‘real’ quantity is not just a number, it has a number and has a non-numeric unit.

So in conclusion:

1. We have extended the notion of gist:Count and gist:CountingUnit to apply to pure numbers that are less than one as well as those that are greater than one.
2. We can represent pure numbers expressed in dozens, percentages, basis points and ppm just like we express the more usual quantities: ‘82 kg’, ‘3 meters’ and ‘20 minutes’.
3. We can use the same computational mechanism to do units conversions on pure numbers as we can for ordinary physical quantities.
4. We can represent gist:Percentage using a new unit called gist:percent with a conversion of .01 instead of using a ratio unit, making a more uniform representation.
5. It will often be helpful to represent a gist:Percentage using a ratio, but it is no longer required.
6. gist:Count could meaningfully and accurately be called gist:PureNumber since every instance of gist:Count (e.g. ‘4 dozen’, ‘65%’) is a pure number (e.g. 48, .65)
7. gist:CountingUnit could meaningfully and accurately be called gist:PureNumberUnit because every instance of gist:CountingUnit is used to express pure numbers.
8. gist:each corresponds to the number one
9. We can think of Counts (pure numbers) and CountingUnits (number units) as degenerate cases of ordinary quantities and units like ’82 kg’ and ‘kg’

Written by Michael Uschold

In a prior blog (SPARQL: Updating the URI of an owl:Class in place) we looked into how to use SPARQL to rename a class in a triple store.  The main steps are below. We showed how to do this for the example of renaming the class veh:Auto to veh:Car.

1. change the instances of the old class to be instances of the new class
2. replace the triples where the class is used in either the subject or object of the triple
3. look around for anywhere else the old class name is used, and change accordingly.

The last step addresses the fact that there are a few other things that you might need to do to address all the consequences of renaming a class.   Today we will see how to handle the situation where your instances use a naming convention that includes the name of the class.  Let’s say the instances of Car (formerly Auto) are all like this:  veh:_Auto_234 and veh:_Auto_12. We will want to change them to be like: veh:_Car_234.

The main steps are:

1. Figure out how you are going to use SPARQL string operations to create the new URI given an old URI.
2. Replace triples using the oldURI in the object of a triple.
   1. Determine where the oldURI is used as the object in a triple, and use CONSTRUCT to preview the new triples using the results of step 1.
   2. Use DELETE and INSERT to swap out the old triples with the new URI in the object.
3. Replace triples using the oldURI in the subject of a triple.
   1. Determine where the oldURI is used as the subject in a triple, and use CONSTRUCT to preview the new triples using the results of step 1.
   2. Use DELETE and INSERT to swap out the old triples with the new URI in the subject

In practice, we do step 1 and step 2a at the same time.  We find a specific instance, and filter on just that one (e.g. veh:_Auto_234) to keep things simple. Because we will be using strings to create URIs, we have to spell the namespaces out in full, or else the URI will incorrectly contain the string “veh:” instead the expanded form, which is: “http://ontologies.myorg.com/vehicles#”.

CONSTRUCT {?s ?p ?newURI}
WHERE {?oldURI rdf:type veh:Car .
       ?s ?p ?oldURI.
       FILTER (?oldURI in (veh:_Auto_234))
       BIND (URI(CONCAT ("http://ontologies.myorg.com/vehicles#_Car_",
                         STRAFTER (STR(?oldURI),"_Auto_")))
             AS ?newURI)
       }

This should return a table something like this:

This tells you there are exactly three triples with veh:_Auto_234 in the object, and shows you what the new triples will be when you replace the old ones.   After this, you might want to remove the FILTER and see a wider range of triples, setting a LIMIT as needed. Now you are ready to do the actual replacement (step 2b).   This is what you do:

1. Add a DELETE statement to remove the triple that will be replaced.
2. Replace the “CONSTRUCT” with “INSERT” leaving alone what is in the brackets.
3. Leave the WHERE clause as it is, except to remove the FILTER statement, if it is still there (or just comment it out).

Sample Graph of Triples

This will do the change in place for all affected triples. Note that we have constructed the URI from scratch, when all we really needed to do was do a string replace.  The latter is simpler and more robust.  Using CONCAT and STRAFTER gives the wrong answer if the string “_Auto_” does not appear in the URI. Here is the query to execute, with the simpler string operation:

DELETE {?s ?p ?oldURI}
INSERT {?s ?p ?newURI }
WHERE {?oldURI rdf:type veh:Car .
       ?s ?p ?oldURI .
       BIND (URI(REPLACE(STR(?oldURI), "_Auto_", "_Car_")) AS ?newURI)
       }

Step 3 is pretty much identical, except flip the subject and object.  In fact, you can combine steps 2 and 3 into a single query.  There are a few things to watch out for:

1. VERY IMPORTANT: make sure you do steps 2 and 3 in order.  If you do step 3 first, you will blow away the rdf:type statements that are needed to do step 2.
2. It is easy to make mistakes, backup the store and work on a copy.
3. When creating URIs from strings, use full namespaces rather than the abbreviated qname format.
4. Check the count of all the triples before and after each time you make a change, track down any differences.

Read Next:

• SPARQL: Updating the URI of an owl:Class in place

Background

We have been developing solutions for our clients lately that involve loading an ontology into a triple store, and building a UI for data entry. One of the challenges is how to handle renaming things.  If you want to change the URI of a class or property in Protégé you load all the ontologies and datasets that use the old URI and use the rename entity command in the Refactor menu.  Like magic, and all references to the URI are changed with the press of the Enter key.   In a triple store, it is not so easy. You have to track down and change all the triples that refer to the old URI. This means writing and executing SPARQL queries using INSERT and DELETE to make changes in place.  Below is an outline of how to rename a class.

Steps of Change

Let ?oldClass and ?newClass be variables bound to the URI for the old and new classes respectively – e.g. ?oldClass might be veh:Auto and ?newClass might be veh:Car.   The class rename operation involves the following steps:

1. Change all instances of ?oldClass to be instances of ?newClass instead. e.g.
   veh:myTeslaS   rdf:type   veh:Auto is replaced with
   veh:myTeslaS   rdf:type   veh:Car
2. Find and examine all the triples using ?oldClass as the object.  It may occur in triples where the subject is a blank node and the predicate is one of the several used for defining OWL  restrictions. E.g . _:123B456x78  owl:someValuesFrom   veh:Auto
   Replace triples with the old class URI in the object with new triples using the  new URI. Note, you might want to do the first part of the next step before doing the replace.
3. Find and examine all the triples using ?oldClass as the subject. It may occur in triples for declaring subclass relationships, comments as well as the triple creating the class in the first place. e.g. veh:Auto   rdf:type   owl:Class
   Replace triples with the old class URI in the subject with new triples using the  new URI.
4. Look around for anywhere else that the old name may be used.  Possibilities include:
   1. If your instances use a naming convention that includes the name of the class (e.g. veh:Auto_234)then you will have to find all the URIs that start with veh:_Auto and use veh:_Car  instead.  We will look into this in a future blog.
   2. The class name may occur in comment strings and other documentation.
   3. It may also be used in SPARQL queries that are programmatically called.

Here is some SPARQL for how to do to the first step.

# Rename class veh:Auto to veh:Car
# For each ?instance of ?oldClass
# Replace the triple <?instance rdf:type ?oldClass>
#               with <?instance rdf:type ?newClass>
DELETE {?instance rdf:type ?oldClass}
INSERT {?instance rdf:type ?newClass}
WHERE  {BIND (veh:Auto as ?oldClass)
        BIND (veh:Car as  ?newClass)
        ?instance rdf:type ?oldClass . }

Gotchas

There are many ways to make mistakes here. Watch for the following:

• Having the DELETE before the INSERT seems wrong, fear not, it is just an oddity in the SPARQL syntax.
• Save out a copy of the triple store, in case things go wrong that are hard to undo.  One way to do this is to make all the changes to a copy of the triple store before making them in the production one. Do all the steps, make sure things worked.
• Make sure your namespaces are defined.
• Before you make a change in place using INSERT and DELETE, always use CONSTRUCT to see what new triples will be created.
• Think about the order in which you replace triples.  You can easily end up replacing triples in one step, that you needed to find the triples to replace in the next step.
• Always check the total count of triples before and after an operation that replaces triples. Generally it should be the same; track down any exceptions.  The count may be less due to duplicate triples that may occur in different named graphs.
• A cautious approach would be to first insert the new triples and on a second step remove the old ones.  I tried this and it did not work, it seems like a bug.  Throw caution to wind, and do the delete and insert at once. You have a backup, and once you get the hang of it, the extra step will just be extra work.
• It may not be possible to fully automate changes in comments and SPARQL queries that are used programmatically.  Check to see what needs to change, and what doesn’t.

What Next?

After you get step 1 working, try out steps 2 and 3 on your own, all you need to do is some straight-forward modifications to the above example.  Step 4 involves more exploration and custom changes.

In an upcoming blog, we explore one of those changes.  Specifically, if your naming convention for instances uses the class name in the URI then those instance URIs will have to change (e.g. from veh:_Auto_2421 to veh:_Car_2421).

Read Next:

• SPARQL: Changing Instance URIs
